Housings 固定式抽風
用途分析
- 排出內部產生的氣體，煙霧，氣溶膠或顆粒物質，防止有害汙染物滲入到實驗室款
- 減少聲音發散
- 不適用於分解反應
- 不適合取代符合EN14175標準的抽風櫃
技術參數
| Dimensions | 900 | 900 | 900 | 900 | |
|---|---|---|---|---|---|
| Width [mm] | 1200 | 1500 | 1800 | 2000 | |
| Depth [mm] |
565 715 750 700 |
||||
| Height [mm] | 1450 | ||||
| Height incl. extract air spigot [mm] | 1550 | ||||
| Height incl. extract manifold [mm] | 1750 | ||||
| Design characteristics | 1200 | 1500 | 1800 | 2000 | |
|---|---|---|---|---|---|
| Construction | Shorter rear panel for using the services if combined with service spines | ||||
| Sash | 2 horizontal sashes | 3 horizontal sashes | |||
| Extract air operation | Connected to on-site extract air system Extract manifold as an option | ||||
| Material lock | Optional | ||||
| Lighting | Optional | ||||
| Shelf board, inside | Optional | ||||
| Ventilation technology | |
|---|---|
| Function display | FAZ as an option |
| Connection height [mm] for extract air spigot Ø 125 mm |
1550 |
| Material | |
|---|---|
| Side panel design, sash | Safety glass |
