Small Scale GMP Production
Integrated filling machine
|
Small Scale GMP Production
Process with lyophilizer
 |
INTERCHANGEABLE FLANGE
SKAN preferred design for the future

Ÿ Aseptic/toxic design (FIPA are placed in front - max. flange width is possible for the filling machine)
Ÿ Machine supplier prefers base plate design
Ÿ A standard needs to be established (customer can select modules
Ÿ from different machine suppliers)
|
Small Scale Filling
Filling Module with Airlock
|
Small Scale GMP Production
Aseptic Technologies, Robot Line L1
|
Small Scale GMP Production
Manual process with two chambers
 |
Small Scale GMP Production
Table top machine, not exchangeable
  |
