Waldner

用途分析

  • 排出內部產生的氣體,煙霧,氣溶膠或顆粒物質,防止有害汙染物滲入到實驗室款
  • 減少聲音發散
  • 不適用於分解反應
  • 不適合取代符合EN14175標準的抽風櫃

技術參數

Dimensions 900 900 900 900
Width [mm] 1200 1500 1800 2000
Depth [mm]

565

715

750

700

Height [mm] 1450
Height incl. extract air spigot [mm] 1550
Height incl. extract manifold [mm] 1750
Design characteristics 1200 1500 1800 2000
Construction Shorter rear panel for using the services if combined with service spines
Sash 2 horizontal sashes 3 horizontal sashes
Extract air operation Connected to on-site extract air system Extract manifold as an option
Material lock Optional
Lighting Optional
Shelf board, inside Optional

Ventilation technology
Function display FAZ as an option
Connection height [mm]
for extract air spigot Ø 125 mm
1550

Material
Side panel design, sash Safety glass
